Sikafloor® MultiDur ET-56 ESD
Sikafloor® MultiDur ET-56 ESD is an ESD epoxy flooring system with a slip resistant textured finish. The system is designed to dissipate electrostatic charges (ESD) and protect sensitive equipment in electrostatic protected areas (EPA).
- Provides reliable and long lasting ESD protection
- Good resistance to specific chemicals
- Electrostatically conductive
- Very good mechanical resistance
- Low VOC emissions
- Low Airborne Molecular Contaminants (AMC) emissions
- Textured gloss finish
Usage
The System can be used in industrial buildings such as:- Automotive facilities
- Electronic facilities and data centres
- Pharmaceutical facilities
- The System may only be used for interior applications.
Advantages
- Provides reliable and long lasting ESD protection
- Good resistance to specific chemicals
- Electrostatically conductive
- Very good mechanical resistance
- Low VOC emissions
- Low Airborne Molecular Contaminants (AMC) emissions
- Textured gloss finish
Colour
Available in the approximate colours: RAL 1014, RAL 5009, RAL 5012, RAL 5024, RAL 6010, RAL 6021, RAL 6027, RAL 7001, RAL 7005, RAL 7011, RAL 7015, RAL 7016, RAL 7024, RAL 7030, RAL 7032, RAL 7034, RAL 7035, RAL 7036, RAL 7037, RAL 7038, RAL 7039, RAL 7040, RAL 7042, RAL 7043, RAL 7045, RAL 7047, RAL 9002, RAL 9005.
Contact Sika representative for available local colour options.
System Details
CERTIFICATES AND TEST REPORTS
Fire Classification Report EN 13501-1, GHENT, No. CR 21-0906-01
System structure
Sikafloor® MultiDur ET-56 ESD
| Layer | Product |
| 1. Primer | Sikafloor®-151 or, Sikafloor®-161 |
| Earthing connection | Sikafloor® Conductive Set |
| 2. Conductive primer | Sikafloor®-220 W Conductive |
| 3. Conductive wearing layer | Sikafloor®-2350 ESD + Sika® Extender T |
Composition
Epoxy
Nominal thickness
~1 mm
Chemical resistance
Sikafloor®-2350 ESD provides the chemical resistance. Refer to Product Data Sheet.
Electrostatic behaviour
| Resistance to ground | RG < 109 Ω |
| Typical average resistance to ground | RG < 105–106 Ω |
| Body voltage generation | < 100 V |
| System resistance | RG < 109 Ω |
Note: Measurement results can be affected by ESD clothing, ambient conditions, measurement equipment, cleanliness of the floor and the test personnel.
IMPORTANT
ESD footwear requirements
The ESD shoes used in the EPA must have a resistance of < 5 MOhm according to IEC 61340-4-3 at climate class 1 (12 % relative humidity / +23 °C). In order to achieve charges of < 30 volts of human body charge during the walking test (at 12 % relative humidity / +23 °C), we recommend using the following ESD shoes: Weeger ESD clog, art. 48512-30, www.schuh-weeger.de.
Service temperature
| Short-term, maximum 12 hours | +60 °C |
IMPORTANT
No simultaneous mechanical and chemical strain
While the product is exposed to temperatures up to +60 °C, do not also subject it to either chemical or mechanical strain, as it may cause damage to the product.
Application
Ambient air temperature
Maximum | +30 °C |
Minimum | +15 °C |
Relative air humidity
Maximum | 80 % |
Dew point
Refer to the individual Product Data Sheet.
Substrate temperature
Minimum | +15 °C |
Maximum | +30 °C |
Substrate moisture content
Refer to the individual Product Data Sheet.
Waiting time to overcoating
For the waiting time to overcoating of the primer, refer to the individual Product Data Sheet.
Before applying Sikafloor®-2350 ESD on Sikafloor®-220 W Conductive, allow:
| Temperature | Minimum | Maximum |
| +15 °C | 26 hours | 7 days |
| +20 °C | 17 hours | 5 days |
| +30 °C | 12 hours | 4 days |
Note: Times are approximate and will be affected by changing ambient conditions, particularly temperature and relative humidity.
Applied product ready for use
Temperature | Foot traffic | Light traffic | Full cure |
+15 °C | ~48 hours | ~3 days | ~7 days |
+20 °C | ~24 hours | ~48 hours | ~4 days |
+30 °C | ~16 hours | ~36 hours | ~3 days |
Note: Times apply when the last layer of the system has been applied. Times are affected by changing ambient conditions, particularly temperature and relative humidity.
Consumption
| Layer | Product | Consumption |
| Primer or scratch coat | Sikafloor®-151 Sikafloor®-161 | ~0.3–0.5 kg/m² |
| Earthing connection | Sikafloor® Conductive Set | 1 earthing point per ~200 m² to 300 m². Min 2 per room |
| Conductive primer | Sikafloor®-220 W Conductive | 1 × 0.08–0.10 kg/m² |
| Conductive wearing layer | Sikafloor®-2350 ESD + Sika® Extender T | ~0.8–1.0 kg/m² + 1.5–2 % (by weight) |
Note: Consumption data is theoretical and does not allow for any additional material due to surface porosity, surface profile, variations in level, wastage or any other variations. Apply product to a test area to calculate the exact consumption for the specific substrate conditions and proposed application equipment.
APPLICATION
Refer to Sika Method Statement.
|
|
|
ESD CONDUCTIVITY MEASUREMENTS
Recommended number of conductivity measurements is specified in the following table:
| Ready applied area | Number of measurements |
| < 10 m² | 6 |
| ≥ 10 m² and < 100 m² | 10 to 20 |
| ≥ 100 m² and < 1000 m² | 50 |
| ≥ 1000 m² and < 5000 m² | 100 |
If the measurements yield values that are outside of the agreed specification, follow these steps:
- Carry out one additional measurement within a radius of approximately 30 cm around the original measuring point.
If the value of the new measurement meets the agreed specification, the original measurement can be disregarded. If the value of the new measurement does not meet the agreed specification, you may repeat the measurement described above, until the fulfilment of the requirements have been verified. If the requirements cannot be verified, contact Sika technical services.
|
|
|
INSTALLATION OF EARTHING POINTS
Refer to Sika Method Statement: Mixing & Application of Flooring Systems.
Number of earthing connections per room: Minimum of 2 earthing connections. The optimum number of earthing connections depends on the local conditions and must be specified on drawings or other contract documentation.
