Product Data Sheet Show all documents

SikaWall®-1030 Alpha Dry Base Coat

(former Senergy® Alpha Dry Base Coat)

DRY-MIX POLYMER BASE COAT

SikaWall®-1030 Alpha Dry Base Coat is a dry-mix polymer base coat containing portland cement and requiring only water for mixing. Part of SikaWall® / Sikatherm® Exterior Insulation and Finish System (EIFS). Suitable for use in hot and tropical climatic conditions.

  • Easy to use, just add water to mix
  • Reduces the chance for efflorescence
  • Trowels easily
  • Easy application, increases job-site productivity
  • Fast mesh embedment
  • Easy installation of corner beads
  • Safe for use, non-toxic
  • Easy to clean
Inquire Now
Product Data Sheet Show all documents

Usage

  • For use with the SikaWall® / Sikaterm® Exterior Insulation and Finish System (EIFS) to be applied as a base coat over insulation board.
  • For use with wall systems to embed SikaWall® Corner Beads and SikaWall® Flexguard Reinforcing Mesh range.
  • To apply insulation plugs over fastener heads, when required.


Advantages

  • Easy to use, just add water to mix
  • Reduces the chance for efflorescence
  • Trowels easily
  • Easy application, increases job-site productivity
  • Fast mesh embedment
  • Easy installation of corner beads
  • Safe for use, non-toxic
  • Easy to clean

Packaging

25 kg bag

Colour

Grey powder

Product Details

Product Information

Composition

Portland cement with special fillers, sand, polymers and additives

Shelf life

12 months from date of production

Storage conditions

Store in original unopened packaging in a cool and dry condition between +5 °C and +30 °C. Protect from direct sunlight, heat and moisture.

Density

~1.7 kg/l (mixed, at +25 °C)


System information

System structure

Air / Vapour barrier (optional)

Sikagard® AWB 661 range

Insulation adhesive

SikaWall®-1010 Alpha Dry Adhesive

Insulation board

EPS / Mineral wool / Sikatherm® range

Mechanical Fasteners

Sikatherm®-900 insulation fasteners range

Corner BeadsSikaWall®-9000 corner bead range
Base CoatSikaWall®-1030 Alpha Dry Base Coat
Reinforcing MeshSikaWall®-9000 Flexguard Mesh range
PrimerSikaWall®-15 Tinted Primer AE
Textured FinishSikaWall®-6000 finish range
Technical Information

Tensile adhesion strength

≥ 0.5 N/mm2

(EN 1542)

Application

Application Information

Mixing ratio

5.6 L per 25 kg bag

Layer thickness

Non-reinforced

Max. 2 mm per layer

Single mesh reinforced

Max. 3 mm per layer

Double mesh reinforced

Max. 5 mm per layer

Ambient air temperature

+5 °C min. / +40 °C max.

Substrate temperature

+5 °C min. / +40 °C max.

Pot Life

+25 °C

~8 hours

+35 °C

~5 hours
Consumption

Consumption

Approximate coverage rates of base coat:

Type of insulation board

Coverage per 25 kg bag for mesh embedment (1st coat)

Expanded

Polystyrene

(EPS)
  • ~13 m2 with embedded SikaWall-9004 Flexguard Mesh
  • ~8 m2 with embedded SikaWall-9012 Intermediate Mesh + SikaWall-9004 Flexguard Mesh (double mesh system)

Mineral wool (Rockwool)
  • ~11.5 m2 with embedded SikaWall-9004 Flexguard Mesh
  • ~6 m2 with embedded SikaWall-9012 Intermediate Mesh + SikaWall-9004 Flexguard Mesh (double mesh system)

Type of insulation boardCoverage per 25 kg bag for final layer (2nd coat)

Expanded

Polystyrene

(EPS) and

Mineral wool (Rockwool)
  • ~24 m2

Note: Flat trowel application. Application rates will depend on the quality of application, substrate board flatness, texture and density. These figures are theoretical and do not allow for any additional material due to surface porosity, surface profile, variations in level, wastage or any other variations. Apply product to a test area to calculate the exact consumption for the specific substrate conditions and proposed application equipment.

Yield

~18 L / 25 kg bag
Application steps

MIXING

  • Place contents of each bag in a suitable container which is clean and free of foreign substances.
  • Do not use a container which has contained or been cleaned with a petroleum-based product.
  • Fill the container with advised amount of clean, potable water.
  • Add SikaWall®-1030 Alpha Dry Base Coat in small increments, mixing after each addition.
  • Mix the contents of the SikaWall®-1030 Alpha Dry Base Coat unit with a low-speed drill and paddle mixer until thoroughly blended.
  • Additional SikaWall®-1030 Alpha Dry Base Coat or small amount of water may be added to adjust workability.
  • Let it stand for 5 minutes, then remix and retemper before use.
  • Additives are not permitted.
  • Close container when not in use.

APPLICATION

Apply the base coat in 2 layers. First (1st) layer of SikaWall®-1030 Alpha Dry Base Coat shall be applied so as to achieve SikaWall® Reinforcing Mesh embedment with no SikaWall® Reinforcing Mesh colour visible. Allow for initial set (touch dry). Lightly abrade dried first layer with sandpaper, without damaging the mesh. Remove the dust and apply second (2nd) layer of SikaWall®-1030 Alpha Dry Base Coat. Allow to dry approx. 8 to 10 hours, depending on the ambient temperature, before the application of SikaWall®-15 Tinted Primer AE and SikaWall®-6000 range of finish coats.

CLEANING OF EQUIPMENT

Clean all tools and application equipment with water and soap immediately after use. Hardened / cured material can only be removed mechanically.
